More comfort & safety through our radio system
Radio receiver
Whatever you want to control
SOMMER receivers make it easy for you.
SOMloq2 - modern radio control system
SOMloq2 is our future-proof radio system in line with modern standards. With 128-bit AES encryption, high transmission security is guaranteed.
Our radio transmitters and receivers allow you to control your systems conveniently and profit from the additional functions of the SOMloq2 system.
SOMcom2.1 (2-channel)
- suitable for special applications (not suitable as a tubular motor control)
- 1 input for gate status to make incompatible operators SOMweb-capable
- feedback of the status of a sensor connected to the input or the relay using a transmitter (e.g. Pearl Status)
- integrated antenna; optional external antenna can be connected
- Memory: 40 radio commands can be programmed
- Slot for memory extension Memo (450 radio commands)
- Area of application: dry, closed rooms
- Control output: 2 potential-free relay contacts (normally open, 1 A, DC 30 V)
- Connection: 8-pin spring terminal
- Active forwarding of the radio signal by SOMloq2 receiver (hop function)
- Compatible with SOMlink S2
- Operating mode:
- Tap mode (Tip): Relay is activated as long as the radio signal is present
- Defined ON/OFF: Command for defined switching on and command for defined switching off
- Switching mode (Toggle): Relay can be switched on and off via radio like a surge relay (can only be set via SOMlink S2)
