工业门开门机 GIGAroll 018.140 CAET0


产品编号: 9077V000
速度
18 rpm
输出扭矩
140 N⋅m
额定功耗
0.55 kW
额定电压
3~230/400 V
额定频率
50 Hz
S3 后的工作制式 ,单位%
ED 60% S3
限位开关范围
14
防护等级
IP54
最低温度
-5 °C
最高温度
60 °C
根据工作环境确定的排放值
< 75dB(A)
d 轴接收
30 mm
  • Emergency hand chain – The emergency chain system can be rotated in 90° units. This allows the position of the chain sprocket to be adjusted for the local conditions.
  • Integrated safety catch with certification for doors that need to be secured against falling
  • Hoist chain DIN 766, 7 m revolving
  • Manual taper in green and red with a 7-metre pull rope
